How I Configured My Beelink S12 Home Server
This post is a point-in-time snapshot of the Beelink S12 home server I use for my own applications.
Architecture Overview
At a high level, the machine has four responsibilities:
- hosts shared infrastructure
- routes inbound app traffic
- persists database state
- runs nightly database backups
Traefik handles inbound HTTP and HTTPS on one Docker network, PostgreSQL stays internal on a separate Docker network, and the app containers are attached to both.
Database backups run nightly via a pair of systemd .timer and .service units installed on the host. Each application's database gets its own compressed dump written to a local backup path and optionally synced to a secondary location. The timer fires at 2 AM every day.
Installed Tools and Services
| Tool / Service | Type | Description |
|---|---|---|
| Docker Engine | Container runtime | Runs and manages all application and infrastructure containers |
| UFW | Firewall | Host-level network access control; default-deny posture |
| Traefik | Reverse proxy | Routes inbound HTTPS traffic to containers via Docker labels |
| PostgreSQL | Database | Shared relational database; internal-only on db-net |
| GlitchTip | Error monitoring | Planned but not yet deployed; DSN placeholder in app config |
| Backup systemd units | Scheduled job | .timer + .service pair; runs daily PostgreSQL dumps at 2 AM |
One detail that stands out here is the split between what is installed on the host and what is intentionally containerized. The host stays fairly lean, while shared services live inside Docker and are isolated by network boundaries.
GlitchTip is listed because the DSN configuration is already in place in the app container environment — activating it is purely a deployment step when the service is ready.
Network Topology
| Network | Type | Members | Purpose |
|---|---|---|---|
traefik-net | Docker bridge | traefik, app containers | Inbound HTTP/HTTPS routing |
db-net | Docker bridge | postgres, app containers | Database access |
The current documented rules are simple:
- Traefik is attached only to
traefik-net. - PostgreSQL is attached only to
db-net. - App containers are dual-homed on both networks.
Traefik is the single entry point for all inbound HTTPS traffic, routing each request to the right application container via Docker labels. PostgreSQL is isolated from the public network and serves as the shared database for every application on the machine.
Data and Persistence
| Item | Purpose |
|---|---|
PostgreSQL data (homelab_pg_data volume) | Persistent database storage |
| Daily backup artifacts | Compressed dumps retained locally; optional copy to secondary target |
| App and service secrets | Runtime credentials, env vars, connection strings — host-managed |
| Reverse proxy config | Traefik entrypoints, TLS, provider config — host-managed |
Logging
Host Docker logging is documented as:
{
"log-driver": "json-file",
"log-opts": {
"max-size": "50m",
"max-file": "5"
}
}That implies a maximum retained log size of 250 MB per container.
Database Layout
| Role | Notes |
|---|---|
Admin (adm) | Full admin access across all databases |
| app1 | Scoped credentials; owns the app1 database only |
| app2 | Scoped credentials; owns the app2 database only |
The isolation model is straightforward:
- One shared PostgreSQL container serves multiple apps.
- Each app gets its own database and user.
Firewall Exposure
The firewall runs UFW with a default-deny posture. The only inbound rules are SSH for administration and the web ports that Traefik listens on. Everything else is blocked, and PostgreSQL has no public-facing rule at all — it is reachable only within the Docker bridge network.
This is the part I like most about the setup. The exposure model is minimal: SSH for administration, web traffic for the reverse proxy, and no direct database exposure at all.
Future Improvements
Two things are at the top of the list: deployment automation and remote access.
On the deployment side, releasing an update currently means building the image, pushing it, SSHing into the machine, and running a few commands manually. The obvious next step is a CI/CD pipeline per application that handles the full cycle automatically.
On the access side, I recently added Tailscale to the server. It gives me a private tunnel so I can reach the machine and its apps from anywhere without opening extra firewall rules or managing dynamic DNS. It has been solid enough that it might deserve its own post.
The setup is stable enough that both of these are quality-of-life improvements rather than urgent fixes. A good baseline to build from.
